L02S-BCN

Smart Beacon

L02S

The L02S-BCN is an intelligent, cloud-connected Smart Beacon, co-designed by Blecon and MOKO SMART to meet the demands of industrial and commercial sensing and connectivity. The L02S-BCN demonstrates what’s possible when established and trusted design meets Bluetooth cloud connectivity.

The L02S-BCN Smart Beacon provides:

  • Two-way communication with cloud confirmation and OTA updates

  • Secure data transport with encrypted payloads and authenticated identity

  • Flexible deployment and roaming using Blecon Hotspots

  • Time-based insights with globally synchronised timestamps

  • On-device intelligence with support for embedded AI/ML









Powered by the Blecon Network



The L02S-BCN connects to the cloud through the Blecon Network via any nearby Blecon-enabled Hotspot. No pairing. No custom gateways.

The Blecon Network enables:

  • Secure device identity, bi-directional communication, geolocation and time services
  • Flexible deployment of network coverage using roaming hotspots—phones, laptops, or gateways—without the need for pairing
  • OTA updates for firmware and ML models
  • Integration with cloud services out of the box using developer-friendly APIs
Blecon Enabled Hubspots


Next Generation Hardware

At the core of the L02S-BCN is the Nordic Semiconductor nRF54L Series system-on-chip (SoC) , with high performance, low power operation, and advanced Bluetooth capabilities. Paired with the Blecon Network, it enables reliable data collection and secure Bluetooth cloud connectivity.

The L02S-BCN includes sensors for temperature, humidity, pressure, and 3-axis acceleration, all housed in a rugged IP67-rated enclosure. Powered by a CR2477 coin cell battery, it’s suited for a wide range of applications, from fixed installations to mobile assets.

Nordic Semiconductor nRF54L Series system-on-chip (SoC) , with high performance, low power operation, and advanced Bluetooth capabilities.


Designed for Integration



The L02S-BCN is built for seamless integration into modern cloud applications and platforms. It provides timestamped, context-rich data over secure Bluetooth connections, with APIs designed for delivering data in to existing systems.

Ideal for asset tracking, equipment auditing, and predictive maintenance, the L02S-BCN supports efficient deployment without adding infrastructure complexity.

Popular integrations include:

  • AWS (S3, SQS, EventBridge)
  • Memfault for observability and OTA
  • Edge Impulse for machine learning
Blecon integrations

L02S-BCN Technical Overview

Specification Summary

System processor Nordic nRF54L15 Series system-on-chip (SoC)
Dimensions 69.9*46.7*18mm Φ45*18mm
IP Rating IP67-rated enclosure
Sensors Temperature and Humidity
Barometric pressure
3-axis Accelerometer
Ambient light
Hall effect
Battery CR2477 battery (1000mAh), field-replaceable
Mounting options Double-sided adhesive, screw, zip-tie



Blecon_Icon_Van_Orange



Order the L02S-BCN

Ready to build using the L02S-BCN Smart Beacons?

You can order samples or volume quantities online:
